BMW X1 (U11): Engines & technical data

TECHNICAL DATA.


Powertrain type	Electric
Power in kW (hp)	150 (204)
Torque in Nm	250
Transmission	1-speed, automatic
Drivetrain	Front-wheel drive


(Nominal) power/30-minutes-power in kW (hp)	150 (204) / 68 (92)
(Nominal) torque in Nm	250


Acceleration 0–100 km/h in s	8.6
Electric top speed in km/h	170

¹
CO2 emissions, combined WLTP in g/km	0
Energy consumption, combined WLTP in kWh/100 km	17.2–15.4
Electric range, WLTP in km ²	430–474
Pass-by noise in dB(A)	66 ⁶

³
Battery capacity in kWh	64.8
Added range after 10 minutes of high-power charging in km ³	132–152
Maximum charging power AC in kW	11 / 22
Charging time AC 0–100% in h	6.5
Maximum charging power DC in kW	130
Charging time DC 10–80% in h	0:29


4,500 mm
1,845 mm
1,616 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,616
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,940
Permissible gross weight in kg	2,435
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 75
Luggage capacity in l	490–1,495


Powertrain type	Electric
Power in kW (hp)	230 (313) ⁷
Torque in Nm	494
Transmission	1-speed, automatic
Drivetrain	All-wheel drive


(Nominal) power/30-minutes-power in kW (hp)	200 (272) / 94 (128)
(Nominal) torque in Nm	494


Acceleration 0–100 km/h in s	5.6
Electric top speed in km/h	180

¹
CO2 emissions, combined WLTP in g/km	0
Energy consumption, combined WLTP in kWh/100 km	18.1–16.9
Electric range, WLTP in km ²	417–439
Pass-by noise in dB(A)	65 ⁶

³
Battery capacity in kWh	64.8
Added range after 10 minutes of high-power charging in km ³	118 - 135
Maximum charging power AC in kW	11 / 22
Charging time AC 0–100% in h	6:30 / 3:45
Maximum charging power DC in kW	130
Charging time DC 10–80% in h	0:29


4,500 mm
1,845 mm
1,616 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,616
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	2,085
Permissible gross weight in kg	2,580
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 75
Luggage capacity in l	490–1,495

⁸
Powertrain type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	230
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

⁸
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	100 (136) / 4,400 - 6,500
Nominal torque in Nm/1/min	230 / 1,500 - 4,000


Acceleration 0–100 km/h in s	9.2
Top speed in km/h	208

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	6.8–6.4
CO2 emissions, combined WLTP in g/km	153–144
Pass-by noise in dB(A)	66 ⁶
Stationary noise level in dB(A) / 1/min	72 / 3,750 ⁶


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,575
Permissible gross weight in kg	2,075
Payload in kg	575
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	540–1,600
Tank capacity in l	54

⁸
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	125 (170) ⁹
Torque in Nm	280 ⁹
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

⁸
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	115 (156) / 4,700 - 6,500
Nominal torque in Nm/1/min	240 / 1,500 - 4,400


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	8.3
Top speed in km/h	216

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	6.1–5.6
CO2 emissions, combined WLTP in g/km	137–128
Pass-by noise in dB(A)	66 ⁶
Stationary noise level in dB(A) / 1/min	72 / 3,750 ⁶

³
Battery capacity in kWh	0.9


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,625
Permissible gross weight in kg	2,120
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	500–1,545
Tank capacity in l	54

⁸
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	160 (218) ⁹
Torque in Nm	360 ⁹
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁸
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	150 (204) / 5,000 - 6,500
Nominal torque in Nm/1/min	320 / 1,500 - 4,000


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	7.1
Top speed in km/h	233

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	6.7–6.3
CO2 emissions, combined WLTP in g/km	152–143
Pass-by noise in dB(A)	66 ⁶
Stationary noise level in dB(A) / 1/min	76 / 3,750 ⁶

³
Battery capacity in kWh	0.9


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,730
Permissible gross weight in kg	2,220
Payload in kg	565
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	500–1,545
Tank capacity in l	54

⁸
Powertrain type	Petrol
Power in kW (hp)	221 (300)
Torque in Nm	400
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁸
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	221 (300) / 5,750 - 6,500
Nominal torque in Nm/1/min	400 / 2,000 - 4,500


Acceleration 0–100 km/h in s	5.4
Top speed in km/h	250

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	8.2–7.7
CO2 emissions, combined WLTP in g/km	185–174
Pass-by noise in dB(A)	67 ⁶
Stationary noise level in dB(A) / 1/min	76 / 3,750 ⁶


4,505 mm
1,845 mm
1,622 mm
Length in mm	4,505
Width in mm	1,845
Height in mm	1,622
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,740
Permissible gross weight in kg	2,240
Payload in kg	575
Luggage capacity in l	540–1,600
Tank capacity in l	54

⁸
Powertrain type	Diesel
Power in kW (hp)	110 (150)
Torque in Nm	360
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

⁸
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	110 (150) / 3,750 - 4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


Acceleration 0–100 km/h in s	8.9
Top speed in km/h	210

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	5.3–5
CO2 emissions, combined WLTP in g/km	140–131
Pass-by noise in dB(A)	67 ⁶
Stationary noise level in dB(A) / 1/min	74 / 3,000 ⁶


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,650
Permissible gross weight in kg	2,150
Payload in kg	575
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	540–1,600
Tank capacity in l	54

⁸
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW (hp)	120 (163) ⁹
Torque in Nm	400 ⁹
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

⁸
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	110 (150) / 3,750 - 4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	8.5
Top speed in km/h	210

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	4.8–4.5
CO2 emissions, combined WLTP in g/km	126–117
Pass-by noise in dB(A)	65 ⁶
Stationary noise level in dB(A) / 1/min	75 / 3,000 ⁶

³
Battery capacity in kWh	0.9


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,685
Permissible gross weight in kg	2,180
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	500–1,545
Tank capacity in l	54

⁸
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW (hp)	120 (163) ⁹
Torque in Nm	400 ⁹
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁸
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	110 (150) / 3,750 - 4,000
Nominal torque in Nm/1/min	360 / 1,500 - 2,500


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	8.6
Top speed in km/h	210

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	5.1–4.8
CO2 emissions, combined WLTP in g/km	133–125
Pass-by noise in dB(A)	65 ⁶
Stationary noise level in dB(A) / 1/min	75 / 3,000 ⁶

³
Battery capacity in kWh	0.9


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,765
Permissible gross weight in kg	2,260
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	500–1,545
Tank capacity in l	54

⁸
Powertrain type	Diesel – 48 Volt Mild-Hybrid
Power in kW (hp)	155 (211) ⁹
Torque in Nm	400
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁸
Cylinders	4
Displacement in cm³	1,995
Nominal power in kW (hp)/1/min	145 (197) / 4,000
Nominal torque in Nm/1/min	400 / 1,500 - 2,750


(Nominal) power/30-minutes-power in kW (hp)	15 (20) / -
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	7.4
Top speed in km/h	225

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km	5.1–4.7
CO2 emissions, combined WLTP in g/km	133–124
Pass-by noise in dB(A)	68 ⁶
Stationary noise level in dB(A) / 1/min	75 / 3,000 ⁶

³
Battery capacity in kWh	0.9


4,500 mm
1,845 mm
1,642 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,642
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,765
Permissible gross weight in kg	2,265
Payload in kg	575
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	500–1,545
Tank capacity in l	54

^{8 ,}¹⁰
Powertrain type	Petrol – Plug-in-Hybrid
Power in kW (hp)	180 (245) ¹¹
Torque in Nm	477 ¹¹
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁸
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	100 (136) / 4,400 - 6,500
Nominal torque in Nm/1/min	230 / 1,500 - 4,000

^{10 ,}¹²
(Nominal) power/30-minutes-power in kW (hp)	80 (109)
(Nominal) torque in Nm	247


Acceleration 0–100 km/h in s	6.8
Top speed in km/h	190
Electric top speed in km/h	140

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km ¹³	0.9–0.7
Fuel consumption with a discharged battery, combined WLTP in l/100 km	6.4–5.9
CO2 emissions, combined WLTP in g/km ¹³	20–16
Energy consumption, combined WLTP in kWh/100 km ¹³	18.2–16.8
Electric range, WLTP in km ²	78–86
Pass-by noise in dB(A)	65 ⁶
Stationary noise level in dB(A) / 1/min	72 / 3,750 ⁶

³
Battery capacity in kWh	14.2
Maximum charging power AC in kW	7.4
Charging time AC 0–100% in h	2:30


4,500 mm
1,845 mm
1,630 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,630
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,930
Permissible gross weight in kg	2,430
Payload in kg	575
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	490–1,495
Tank capacity in l	47

^{8 ,}¹⁰
Powertrain type	Petrol – Plug-in-Hybrid
Power in kW (hp)	240 (326) ¹¹
Torque in Nm	477 ¹¹
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

⁸
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW (hp)/1/min	110 (150) / 4,700 - 6,500
Nominal torque in Nm/1/min	230 / 1,500 - 4,400

^{10 ,}¹²
(Nominal) power/30-minutes-power in kW (hp)	130 (177)
(Nominal) torque in Nm	247


Acceleration 0–100 km/h in s	5.6
Top speed in km/h	205
Electric top speed in km/h	140

^{8 ,}¹
Fuel consumption, combined WLTP in l/100 km ¹³	0.9–0.7
Fuel consumption with a discharged battery, combined WLTP in l/100 km	6.4–6
CO2 emissions, combined WLTP in g/km ¹³	21–16
Energy consumption, combined WLTP in kWh/100 km ¹³	18.2–16.8
Electric range, WLTP in km ²	77–85
Pass-by noise in dB(A)	65 ⁶
Stationary noise level in dB(A) / 1/min	72 / 3,750 ⁶

³
Battery capacity in kWh	14.2
Maximum charging power AC in kW	7.4
Charging time AC 0–100% in h	2:30


4,500 mm
1,845 mm
1,630 mm
Length in mm	4,500
Width in mm	1,845
Height in mm	1,630
Width incl. mirrors (driver / passenger side) in mm	2,104
Wheelbase in mm	2,692
Vehicle curb weight in kg ⁴	1,935
Permissible gross weight in kg	2,435
Payload in kg	575
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁵	- / 80
Luggage capacity in l	490–1,495
Tank capacity in l	47

1 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

2 Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

3 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

4 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

5 Trailer load depends on the vehicle options

6 The values measured in accordance with UN/ECE Regulation No. 51/EU Regulation 540/2014 are rounded.

7 Temporary uprating <10 seconds in excess of specified nominal value

8 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 1151/2017. Unleaded RON 91 and higher with a maximum ethanol content of 25% (E25) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

9 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).

10 For plug-in hybrid: Electric drive depending on battery charging level.

11 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.

12 For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.

13 For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Find out more

Consumption and CO2 emissions.

BMW X1 xDrive23i:
Fuel consumption, combined WLTP in l/100 km: 6.7–6.3
CO2 emissions, combined WLTP in g/km: 152–143

BMW X1 xDrive30e:
Fuel consumption, combined WLTP in l/100 km: 0.9–0.7
CO2 emissions, combined WLTP in g/km: 21–16
Energy consumption, combined WLTP in kWh/100 km: 18.2–16.8

BMW iX1 xDrive30:
Energy consumption, combined WLTP in kWh/100 km: 19.0–16.9
CO2 emissions, combined WLTP in g/km: 396–440

Electric cars

Charging an electric car

Shop Online

Digital Services & Apps

Service & Workshop

Technology & Innovation

Parts & Accessories

BMW SPECIAL SALES

CONCEPT CAR

Website currently not fully available

BMW X1: ENGINES & TECHNICAL DATA.

TECHNICAL DATA.

BMW WHEELS & TYRES.
